以具有两大特色技术为基础的新型高参数废热锅炉及各型换热设备

New high parameter waste heat boiler and various heat exchange equipment based on two characteristic technologies

特色一：

挠性薄管板及管头保护技术，以及渗透换热设备高温温控技术和防护技术达到最大限度降低热端管头和管板表面金属温度，防止高温硫化、高温氧化、高温碳化高温氢化，防止材质软化的效果。

特色二：

应用汽水循环新概念，对汽水循环倍率的新的认知，大为简化结构和流程，减少加工和施工难度，减少设备运行和辅助结构钢材用量，稳定运行，方便操作。

Feature 1:

Flexible thin tube sheet and tube head protection technology, as well as high-temperature temperature control technology and protection technology for permeation heat exchange equipment, achieve the maximum reduction of metal temperature on the surface of the hot end tube head and tube sheet, prevent high-temperature vulcanization, high-temperature oxidation, high-temperature carbonization, high-temperature hydrogenation, and prevent material softening.

Feature 2:

By applying the new concept of steam water cycle and gaining a new understanding of steam water cycle ratio, the structure and process are greatly simplified, processing and construction difficulties are reduced, equipment operation and auxiliary structural steel consumption are reduced, stable operation is achieved, and operation is facilitated.
